Description
A WHOLE NEW WORLD OF FUN, THE SWAMP MASTER IS THE FIRST FULL SUSPENSION COMPLETE BMX BIKE. INSPIRED BY THE WORLD OF DOWNHILL MOUNTAIN BIKING, MIXED WITH CLASSIC BMX ROOTS AND FUN, THIS BIKE IS UNIQUE TO SAY THE LEAST. ENGINEERED IN COLOGNE, GERMANY, THE SWAMP MASTER IS DESIGNED FOR SERIOUS DOWNHILL SHREDDING WHILST GAINING THE MOVEMENT AND FREEDOM THAT A BMX BIKE OFFERS. SPEC’D WITH A MIXTURE OF OUR OWN AFTERMARKET BMX COMPONENTS AND GENUINE MTB PARTS FROM KENDA AND MANITOU, THE SWAMP MASTER IS THE FIRST PRODUCTION COMPLETE BIKE OF ITS KIND AND IS SET TO REVOLUTIONISE A NEW CHAPTER IN BMX AND MTB FUSION
Specifications
FRAME:WETHEPEOPLE “SWAMP MASTER” FRAME, 4130 FULL CRMO, (ROCKSHOX MONARCH RL* / SUNTOUR RAIDON LO* – DEPENDING ON AVAILABILITY)FORK:MANITOU “MACHETE J-UNIT COMP” FORK, CUSTOM TUNED, 100MM TRAVEL, THRU-AXLEBARS:WETHEPEOPLE “SWAMP MASTER” BAR, POST LIQUID HEAT-TREATED 4130 CRMOGRIPS:SALT “EX” GRIPS, 154MM, FLANGLESSSTEM:ÉCLAT “BURNS TOPLOAD STEM, CNC ALLOY, 51MM REACHHEADSET:WETHEPEOPLE “COMPACT” INT. HEADSET, SEALED BEARINGGYRO:-LEVER:BENGAL “ARES 3” DISC BRAKE LEVERSBRAKES:BENGAL “ARES 3” HYDRAULIC DISC BRAKES, 160 MM ROTORSCRANKSWETHEPEOPLE “LOGIC” TUBULAR 3PC CRANK, 22MM, CRMO, 175MM, 48 SPLINEBB:WETHEPEOPLE “COMPACT” BB, 22MM, PRESS FIT, SEALED BEARINGPEDALS:WETHEPEOPLE “LOGIC” PEDALS, NYLON/FIBERGLASSCHAIN:ÉCLAT “DIESEL” CHAINSPROCKET:WETHEPEOPLE “PATROL” SPROCKET, CNC, 6061-T6 ALLOY, 28TDRIVER:1PC CASSETTE DRIVER, 9T, SEALED BEARING, 6 PAWL, 120 POEFRONT HUB:ÉCLAT “EXILE” DISC FRONT HUB, BOOST 110MM, FULLY SEALED, 15MM THRU AXLE, 36HREAR HUB:ÉCLAT “EXILE” DISC CASSETTE HUB, FULLY SEALED, 3/8″ FEMALE BOLTS, 36H, 120 POEHUBGUARDS:-FRONT RIM:ÉCLAT “BONDI” RIM, 38MM WIDE, FLASH WELDED, DOUBLE WALL, 36HREAR RIM:ÉCLAT “BONDI” RIM, 38MM WIDE, FLASH WELDED, DOUBLE WALL, 36HSEAT:ÉCLAT “BIOS” PIVOTAL SEAT, SLIM PADDEDSEAT POST:WETHEPEOPLE “TEAM” PIVOTAL SEAT POST, 200MM LONG, 6061-T6 ALLOYSEAT CLAMP:INTEGRATED SEAT CLAMPTIRES:KENDA “KAOS” TIRES, 20″X 2.6″, FRONT & REARPEGS:-WEIGHT:14.5KG / 31.97LBSCOLORS:MATT BLACK
Geometry
FRAME
A – TOP TUBE LENGTH:21.5″B – CHAIN STAY LENGTH:14.1″-14.8″C – HEAD TUBE ANGLE:71°D – SEAT TUBE ANGLE:70°E – BB HEIGHT:12.15″F – STANDOVER HEIGHT:9.5″
HANDLE BAR
G – BAR RISE:8″H – BAR WIDTH:29.15″I – BAR BACK SWEEP:11°J – BAR UP SWEEP:2.5°
